Engineered specifically for interior architectural applications where surface appearance and tactile quality are primary criteria. Features a specialized anti-fingerprint (AFP) nano-coating that creates a nano-structured surface layer resistant to fingerprint marks, skin oil deposition, and handling smudges. Combined with a premium matte finish coating at 15-25 GU gloss, it delivers the aesthetic characteristics demanded by interior designers for commercial interiors, retail spaces, and hospitality venues. The AFP-treated matte finish maintains clean appearance even after repeated contact during installation and daily use.
Key Features| Parameter | Specification |
|---|---|
| Substrate Grade | DX51D+Z |
| Thickness Range | 0.25mm - 0.80mm |
| Width Range | 600mm - 1250mm |
| Zinc Coating | Z60 - Z100 g/m² |
| Top Coating | PE/SMP + AFP Nano |
| Gloss (60°) | 15-25 GU Matte |
| Surface Flatness | ≤ 3 I-unit |
| Finishes | Solid/Wood/Stone/Metallic |
| Coil Weight | 2-5 tons |
Suspended ceiling panels and grid systems, interior partition and movable wall panels, elevator cabin panels and door skins, office furniture panels and storage systems, decorative column covers, interior door skins, display and exhibition panels, acoustic panel face sheets. Compatible with shearing, punching, bending, roll forming, and adhesive bonding.
Packaging & Quality AssurancePolyethylene film interleaving, soft-edge coil protectors, moisture barrier wrapping, padded pallets. Documentation includes mechanical properties, ISO 2409 cross-hatch adhesion, AFP contact angle measurement, color/gloss consistency, flatness reports, and VOC emission certificates. ISO 9001 with automated optical inspection (AOI) below 0.2mm defect detection.
