Matt Finish PPGL Galvalume Steel Coil AZ150 Premium Grade For Villa Hotel Commercial Building Facade Roof Decor
  • Matt Finish PPGL Galvalume Steel Coil AZ150 Premium Grade For Villa Hotel Commercial Building Facade Roof Decor
  • Matt Finish PPGL Galvalume Steel Coil AZ150 Premium Grade For Villa Hotel Commercial Building Facade Roof Decor

Matt Finish PPGL Galvalume Steel Coil AZ150 Premium Grade For Villa Hotel Commercial Building Facade Roof Decor

Place of Origin Shandong, China
Brand Name ECER
Certification ISO 9001:2015, SGS, BV
Model Number PPGI-08
Product Details
Highlight:

Matt finish PPGL steel coil

,

Galvalume steel coil for facade

,

AZ150 premium grade steel coil

Payment & Shipping Terms
Minimum Order Quantity
3 Tons
Price
550-850 USD/Ton
Packaging Details
Waterproof Paper + Metal Edge Protector + Steel Strapping + Wooden Pallet, Seaworthy Export Packaging
Delivery Time
15-25 Working Days
Payment Terms
L/C, T/T, Western Union
Supply Ability
5000 Tons per Month
Product Description

Combines superior corrosion resistance of 55% Aluminum-Zinc alloy coating (AZ150) with a sophisticated low-gloss paint finish, creating the definitive material solution for premium architectural projects. The Galvalume substrate offers 2-4 times the atmospheric corrosion resistance of conventional galvanized coatings, particularly in thermal cycling and condensation exposure. The matt finish at 15-25 GU creates a soft, non-reflective surface that minimizes solar glare and masks minor surface irregularities, while the Al-Zn alloy provides superior cut-edge protection through a unique electrochemical mechanism.

Key Features
  • AZ150 Galvalume Substrate: 55% Al-Zn alloy provides 2-4x atmospheric corrosion resistance of galvanized coatings, superior in thermal cycling and condensation.
  • Architectural Matt Finish: Low-gloss 15-25 GU delivers contemporary aesthetic with reduced glare and improved visual consistency across large facades.
  • Superior Cut-Edge Protection: Al-Zn alloy provides enhanced sacrificial protection at cut edges, punched holes, and profile cut ends versus pure zinc.
  • Heat Reflectivity: Aluminum content combined with light-colored matt finishes improves solar reflectance, reducing building cooling loads in hot climates.
  • Premium Paint Options: Available with SMP for 15-year or PVDF for 25-year architectural warranty to match project lifecycle requirements.
  • Dimensional Stability: Lower thermal expansion than aluminum sheet reduces oil-canning and thermal movement in long panel runs.
Technical Specifications
ParameterSpecification
SubstrateGalvalume 55% Al-Zn
CoatingAZ100 - AZ150
Thickness0.30mm - 1.20mm
Width700mm - 1250mm
Top CoatingSMP / PVDF 20-25 μm
Gloss (60°)15-25 GU Matt
Service Life15-25 Years Exterior
Coil ID508mm / 610mm
Coil Weight3-8 tons
Applications

Villa roof and facade cladding, boutique hotel exterior panels, luxury resort roofing and walls, corporate headquarters facades, high-end retail exteriors, museum and cultural center metal roofing, premium residential roof tiles, custom architectural metalwork including sunshades, canopies, and feature elements. Compatible with standing seam, cassette panel, interlocking tile, and flat lock systems.

Packaging & Quality Assurance

Soft non-woven fabric interleaving, VCI paper wrapping, reinforced edge protection, multiple steel banding, ISPM 15 pallets. Documentation per ASTM A792 or EN 10346, AZ coating XRF verification, AAMA 2604/2605 paint performance including QUV, salt spray, humidity, and color/gloss consistency. Full traceability from coil origin to finished product.
