Color Coated Steel Coil
>
Combines superior corrosion resistance of 55% Aluminum-Zinc alloy coating (AZ150) with a sophisticated low-gloss paint finish, creating the definitive material solution for premium architectural projects. The Galvalume substrate offers 2-4 times the atmospheric corrosion resistance of conventional galvanized coatings, particularly in thermal cycling and condensation exposure. The matt finish at 15-25 GU creates a soft, non-reflective surface that minimizes solar glare and masks minor surface irregularities, while the Al-Zn alloy provides superior cut-edge protection through a unique electrochemical mechanism.
Key Features| Parameter | Specification |
|---|---|
| Substrate | Galvalume 55% Al-Zn |
| Coating | AZ100 - AZ150 |
| Thickness | 0.30mm - 1.20mm |
| Width | 700mm - 1250mm |
| Top Coating | SMP / PVDF 20-25 μm |
| Gloss (60°) | 15-25 GU Matt |
| Service Life | 15-25 Years Exterior |
| Coil ID | 508mm / 610mm |
| Coil Weight | 3-8 tons |
Villa roof and facade cladding, boutique hotel exterior panels, luxury resort roofing and walls, corporate headquarters facades, high-end retail exteriors, museum and cultural center metal roofing, premium residential roof tiles, custom architectural metalwork including sunshades, canopies, and feature elements. Compatible with standing seam, cassette panel, interlocking tile, and flat lock systems.
Packaging & Quality AssuranceSoft non-woven fabric interleaving, VCI paper wrapping, reinforced edge protection, multiple steel banding, ISPM 15 pallets. Documentation per ASTM A792 or EN 10346, AZ coating XRF verification, AAMA 2604/2605 paint performance including QUV, salt spray, humidity, and color/gloss consistency. Full traceability from coil origin to finished product.
